Sab hauv AC Hlau -clad Withdrawable Switchgear
Product Description
Cov hlau AC sab hauv tsev -clad tshem tau switchgear yog qhov nruab nrab -voltage main distribution panel rau substations thiab industrial tis chav tsev uas yuav tsum tau muaj kev nyab xeeb, tswj fais fab kev faib tawm. Nws cov hlau-clad, compartmentalized qauv khaws lub breaker, busbar, cable thiab relay/instrument compartments lub cev sib cais los ntawm cov hlau partitions, muaj arc faults thiab txhim kho tus neeg teb xov tooj kev nyab xeeb. Lub tshuab nqus tsev twj tso kua mis yog ntsia rau ntawm lub tsheb thauj khoom thiab tuaj yeem txav mus los ntawm kev sib txuas, sim thiab txiav txoj haujlwm, tso cai rau kev tshuaj xyuas thiab kev saib xyuas yam tsis muaj de- ua kom lub zog nyob ib sab. Interlock mechanisms tiv thaiv kev ua haujlwm tsis raug xws li kaw rau hauv lub ntiaj teb ua txhaum lossis qhib lub qhov rooj hauv qhov chaw thau khoom.
Qhov no switchgear yog tsim nyob rau hauv KYN28-12, KYN28-24 thiab KYN61-40.5 series, yog li voltage chav kawm ntawv, ntsuas tam sim no thiab luv luv-circuit withstand rating tuaj yeem phim rau qhov project specification es tsis yog hloov tom qab xa khoom. Engineering tau lees paub tawm tsam tus neeg siv khoom daim duab kos ib kab ua ntej tsim khoom, thiab txhua lub vaj huam sib luag tau dhau los ua ib feem ntawm kev kuaj xyuas, kev kuaj xyuas hluav taws xob thiab 100% kev tshuaj xyuas ua ntej ntim ntoo-crate.
Specifications
|
Parameter |
Specification |
|
Series |
KYN28-12 / KYN28-24 / KYN61-40.5 |
|
Rated Voltage |
12 kV / 24 kV / 40.5 kV |
|
Rated Tam sim no |
630A - 3150A (customizable) |
|
Luv -Lub Sijhawm Nrog Tam Sim No |
20 kA - 50 kA / 4 s (ib spec) |
|
Hom Breaker |
Tshem tawm lub tshuab nqus tsev Circuit Court breaker |
|
Qauv |
Hlau -clad, compartmentalized steel |
|
Qib tiv thaiv |
IP4X (sab hauv), IP2X (qhov rooj qhib) |
|
Component Brands |
Schneider, Siemens, Chint, Delixi (ib spec) |
Daim ntawv thov
Industrial substations
Ua hauj lwm raws li qhov nruab nrab nruab nrab-voltage faib vaj huam sib luag rau transformer feeders thiab loj lub cev muaj zog circuits, qhov twg txhim khu kev qha hloov thiab kev saib xyuas yog qhov tseem ceeb.
Mining thiab kev lag luam hnyav
Withstands siab txhaum tam sim no thiab nquag hloov ua haujlwm, thiab lub tsheb thauj khoom tshem tawm tuaj yeem ua rau lub sijhawm tu ncua hauv qhov xav tau ib puag ncig.
Commercial thiab industrial parks
Cov qauv tsim tawm tuaj yeem txo qis kev cuam tshuam lub zog thaum lub sijhawm hloov pauv, txhawb kev txuas ntxiv ntawm cov khoom lag luam sib xyaw.
Kev kho kom haum
Peb kho cov hlau tshem tau-clad switchgear hla cov chav kawm voltage, ntsuas tam sim no, luv luv-circuit tiv thaiv kev ntsuas, breaker hom thiab qauv, tiv thaiv relay configuration, metering thiab instrumentation, busbar configuration, enclosure qhov ntev thiab cov neeg siv khoom npe. Kev tsim khoom yog raws li kev lees paub ib leeg - kab kos duab thiab kos duab kos duab.
Ntim & Kev thauj mus los
Txhua lub vaj huam sib luag yog qhwv hauv zaj duab xis tiv thaiv thiab ntim rau hauv ib lub thawv ntoo nrog rau sab hauv los tiv thaiv- kev sib tsoo padding. Cov ntsiab lus kev lag luam txhawb nqa: FOB rau qhov chaw nres nkoj Suav thiab EXW. Kev Them Nyiaj: 40% tso nyiaj, 80% tom qab kuaj ua ntej- khoom xa tuaj, tshuav nyiaj li cas ntawm qhov chaw nres nkoj Suav.
FAQ
Q: Koj puas tuaj yeem tsim qhov hloov pauv no raws li peb ib leeg - kab kos duab?
A: Yog. Peb ua nruj me ntsis raws li cov neeg siv khoom- muab hluav taws xob schematics, layout drawings los yog technical data sheets, nrog engineering kev pom zoo ua ntej ntau lawm.
Q: Koj ua qhov kev kuaj zoo li cas ua ntej xa zaub mov?
A: Txhua lub vaj huam sib luag tau dhau los ntawm kev ntsuas lub zog, ntsuas qhov tso tawm ib nrab, kev ntsuas kev tiv thaiv kev tiv thaiv hluav taws xob thiab kev kuaj xyuas kev ua haujlwm, nrog 100% kev tshuaj xyuas thiab kev lees paub ntawm thib peb - kev tshuaj ntsuam xyuas.
Q: Lub sijhawm khoom xa tuaj yog dab tsi?
A: Nyob ntawm chav kawm voltage, specification thiab xaj kom muaj nuj nqis, tus qauv xa khoom feem ntau yog 3 lub lis piam mus rau 1 lub hlis.
